Constructed to withstand harsh environments, compact, wire-braided pressure washer wash down hoses have been increasingly used. This product was developed to be smaller in diameter than conventional one-and-two braided hoses with similar performance characteristics. Thus, the smaller diameter gives the following characteristics:
- Smaller bend radii
- Smaller OD lower profile - takes up less space on a reel
- Extraordinary flexibility - superior flex performance
- Less weight - easier to handle
- Hoses are oil, fuel, weather, ozone and abrasion resistant
- Temperature range - 40° F to 212° F constant operating temperature
- Hoses are fitted with solid male x male swivel end and bend guards
Synthetic Rubber (ONE WIRE) Black Outer Cover Specifications
Hose I.D. |
Hose O.D. | Min. Burst |
Max Working PSI |
Mid. Bend |
lbs./100' |
3/8" | .638" | 12,500 PSI | 4,000 PSI | 2.5" | 18 lbs. |
1/2" | .750" | 10,000 PSI | 3,000 PSI | 3.5" | 27 lbs. |
Synthetic Rubber (TWO WIRES) Black Outer Cover Specifications
Hose I.D. | Hose O.D. |
Min. Burst | Max Working PSI |
Mid. Bend |
lbs./100' |
3/8" | .638" | 20,000 PSI | 6,000 PSI | 2.5" | 18 lbs. |
1/2" | .750" | 18,000 PSI | 4,500 PSI | 3.5" | 27 lbs. |
One Wire 3/8” Hose - Note: P/N + Length = Hose P/N
P/N: PW138X
Size: 3/8”
Lengths Available: 10’, 25’, 50’, 75’, 100’, 150’, 200’, 250’, 300’
Two Wire 3/8” Hose - Note: P/N + Length = Hose P/N
P/N: PW238X
Size: 3/8"
Lengths Available: 10’, 25’, 50’, 75’, 100’, 150’, 200’, 250’, 300’
One Wire 1/2” Hose Note: P/N + Length = Hose P/N
P/N: PW112X
Size: 1/2”
Lengths Available: 10’, 25’, 50’, 75’, 100’, 150’, 165’
Two Wire 1/2” Hose Note: P/N + Length = Hose P/N
P/N: PW212X
Size: 1/2”
Lengths Available: 10’, 25’, 50’, 75’, 100’, 150’, 165’
Call us today for pricing and availability - (877) 389-9999.
